Home Products Products LED tubes & PL T8 LED tubes EM+AC 1200mm (36W) Sensor

LED T8 Sensor On-Off 1200 G13 18W (36W) 2000lm 840 EM+AC

Article number: 146346

BAI Ecoplus T8 Sensor On/Off LED Tube 29x1200mm G13 18W (36W) 2000lm 4000K CRI80 Glass EM Retrofit + AC 230V-240V 280° Temp. -20°C +40°C Alt T26 TLD Lumilux LED-lamp

LED Ecoplus T8 tube with a G13 fitting and motion sensor. After detection, the lamp lights up to 100%. After 90 seconds without detection, the LED tube switches off. Disconnecting magnetic ballast is optional, not necessary. Not suitable for series connection. 5.8GHz microwave sensor. Detection range Max. 5m. The distance between two tubes should be at least 1.5m! Replace the fluorescent starter with the LED starter (supplied). Ambient temperature range: -20°C to +40°C.

Please read the manual before use.

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED T8 Sensor On-Off 1200 G13 18W (36W) 2000lm 840 EM+AC
Brand
Bailey
Productseries
Ecoplus LED tube
Producttype
T8 Sensor
GTIN
8714681463468
Manufacturer articlenumber
146346

ETIM specifications

Socket
G13
Luminous flux [lm]
2000 - 2000
Nominal voltage [V]
220 - 240
Lamp power [W]
18 - 18
Colour temperature [K]
4000 - 4000
Diameter [mm]
29
Length [mm]
1200
Dimmable
No
Lamp shape
Tube, double-ended
Beam angle [°]
280 - 280
Colour
White
Type of glass/cover
Opal
Lamp designation
T8
Colour rendering index CRI
80-89
Voltage type
AC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
2000
Power factor
0.9
Lamp efficacy [lm/W]
111
Nominal current [mA]
91 - 91
Colour of light according to EN 12464-1
Neutral white 3300-5300 K
Housing colour
White
Average nominal lifetime [h]
30000
Degree of protection (IP)
IP20
Energy efficiency class
E
Colour consistency (McAdam ellipse)
SDCM6
Min. number of switching cycles
15000
Weighted energy consumption in 1000 hours [kWh]
18
Remote operation possible
No
With movement sensor
Yes
With remote control
No
Photobiological safety according to EN 62471
RG0
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
Yes
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
E
With twilight switch
No
Material of light bulb
Glass
Downloads
Manual
IM_LEDT8EMAC_Sensor-OnOff-01.pdf
