T5 8W 840 16X288 Emergency
Article number: 145957
BAI T5 G5 16X288mm 8W/33 4000K Specfill Emergency lighting Fluorescent lamp
These lamps are specially designed for high-frequency emergency operation, and are also a perfect fit and a premium solution in any other T5 Miniature application. The robust cathode design of these lamps ensure very good reliability at low operating power in emergency mode as well as extending the lifetime in normal operation with use of an EVSA to 5.000 hours. The avarage lifetime without EVSA will be ± 2500 hours.
Data not available (yet). Please contact our sales department for more information.
General ETIM properties
ETIM group
Lamps
ETIM class
Fluorescent lamp
Name
T5 8W 840 16X288 Emergency
Brand
Bailey
Productseries
Fluorescent
Producttype
T5 Emergency
GTIN
8714681459577
Manufacturer articlenumber
145957
ETIM specifications
Socket
G5
Lamp power [W]
8
Length [mm]
288
Tube diameter [mm]
16
Colour temperature [K]
4000
Colour of light
840
Lamp shape
Rod
Lamp efficacy [lm/W]
47.5
Colour rendering index CRI
80-89
Colour of light according to EN 12464-1
Neutral white 3300-5300 K
Luminous flux [lm]
380
Ring diameter [mm]
0
Internal reflector
No
Beam angle [°]
360
Colour
White
Application
General
Splitter protection
No
Ignition strip
No
Fast ignition
No
Starterless operation
No
Full spectrum lamp
No
Suitable for explosion proof luminaires
No
Suitable for emergency lighting
Yes
Double-walled
No
For application at low temperatures
No
Energy efficiency class
G
Weighted energy consumption in 1000 hours [kWh]
8
Average nominal lifetime [h]
5000
Lamp designation
T5
Energy efficiency class according to EU regulation 2019/2015
G
