LED Spot Black R111/ES111 G53 12V 16W 680lm 822 15° DIM
Article number: 143311
BAI BaiSpot Black LED Reflector R111/ES111 G53 12V/AC 16W 2200K 15D 680lm (70W) Dimmable 111x56mm AR111 LED-lamp
Ambient temperature range: -20°C to +35°C
Data not available (yet). Please contact our sales department for more information.
General ETIM properties
ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED Spot Black R111/ES111 G53 12V 16W 680lm 822 15° DIM
Brand
Bailey
Productseries
BaiSpot LED LV
Producttype
R111 Black SCOB
GTIN
8714681433119
Manufacturer articlenumber
143311
ETIM specifications
Socket
G53
Luminous flux [lm]
680 - 680
Nominal voltage [V]
12 - 12
Lamp power [W]
16 - 16
Colour temperature [K]
2200 - 2200
Diameter [mm]
111
Length [mm]
56
Dimmable
Yes
Lamp shape
Reflector
Colour
White
Lamp designation
Other
Colour rendering index CRI
80-89
Voltage type
AC
Filament lamp
No
Luminous intensity [cd]
3500
Power factor
0.9
Lamp efficacy [lm/W]
43
Nominal current [mA]
1300 - 1300
Colour of light according to EN 12464-1
Warm white < 3300 K
Housing colour
Black
Average nominal lifetime [h]
45000
Degree of protection (IP)
IP20
Energy Efficiency Index (EEI)
0.3
Energy efficiency class
G
Colour consistency (McAdam ellipse)
SDCM6
Min. number of switching cycles
25000
Weighted energy consumption in 1000 hours [kWh]
16
Remote operation possible
No
With remote control
No
Photobiological safety according to EN 62471
RG1
Dimmer compatibility list
