Home Products Products LED tubes & PL PL LED 2-pin G24d TC-D (26W)

LED PL TC-D G24d 2P 10W (26W) 970lm 830 FR EM+AC

Article number: 143155

BAI LED PL G24d 2-pins TC-D 10W (26W) 3000K Frosted 970lm EM Retrofit + AC 230V-240V 130° 36x164mm Rotating cap LED-lamp Alt PLC Dulux D

The LED PL G24d AC + EM (2-pin) TC-D lamps with rotating base are LED replacements for the commonly used compact fluorescent lamps. PL stands for PubLic as these lamps are mainly used in wall and ceiling luminaires in public areas, offices, shops and restaurants. Fast and simple 1-to-1 replacement in luminaires with conventional ballast or mains voltage. Installation: Disconnecting magnetic ballast is optional, not necessary. Always read the manual carefully before installation. Only suitable for temperatures up to 40°C in the fixture.

Please read the manual before use.

Data not available (yet). Please contact our sales department for more information.

Request a quote for this article

Click here for Eprel specifications

General ETIM properties

ETIM group
Lamps
ETIM class
LED-lamp/Multi-LED
Name
LED PL TC-D G24d 2P 10W (26W) 970lm 830 FR EM+AC
Brand
Bailey
Productseries
LED PL
Producttype
G24d 2P EM+AC
GTIN
8714681431559
Manufacturer articlenumber
143155

ETIM specifications

Socket
G24d
Luminous flux [lm]
970 - 970
Nominal voltage [V]
220 - 240
Lamp power [W]
10 - 10
Colour temperature [K]
3000 - 3000
Diameter [mm]
36
Length [mm]
164
Dimmable
No
Lamp shape
Tube, single-ended
Beam angle [°]
130 - 130
Colour
White
Type of glass/cover
Frosted
Lamp designation
Other
Colour rendering index CRI
80-89
Voltage type
AC
Filament lamp
No
Rated luminous flux according to IEC 62612 [lm]
970
Power factor
0.7
Lamp efficacy [lm/W]
97
Nominal current [mA]
87 - 87
Colour of light according to EN 12464-1
Warm white < 3300 K
Housing colour
White
Average nominal lifetime [h]
20000
Degree of protection (IP)
IP20
Energy Efficiency Index (EEI)
0.13
Energy efficiency class
No
Colour consistency (McAdam ellipse)
SDCM5
Min. number of switching cycles
15000
Weighted energy consumption in 1000 hours [kWh]
10
Remote operation possible
No
With movement sensor
No
With remote control
No
Photobiological safety according to EN 62471
RG1
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No
Suitable for electronic ballast
No
Suitable for magnetic ballast
Yes
Dimming phase cut-off (trailing edge)
No
Dimming phase cut-on (leading edge)
No
Dimming Touch and Dim
No
Dimming Zigbee
No
Dimming Bluetooth
No
Dimming Wi-Fi
No
No dim function
Yes
Energy efficiency class according to EU regulation 2019/2015
No
With twilight switch
No
Material of light bulb
Plastic
Downloads
Manual
IM_LED_PL_G24EMAC-01.pdf
Cross-reference list
Bailey_Cross_Reference_LED_PL-2pins.pdf
